Technical service / 02
Technical information made clear in the model.
We organise MEP geometry, data, schedules, and drawings in Revit.
Service 02
view_in_ar
ARILVO / MEP · BIM
MEP information model
Information model
Useful geometry carries consistent information.
The model stays reviewable, coordinated, and connected to required outputs.
verified_user
Scope defined before appointment
We define roles, development level, deliverables, and local-partner needs for each phase.
01
Structured MEP geometry
Systems modelled to the agreed phase and purpose.
view_in_ar
02
Data and schedules
Data structured to keep elements and quantities reviewable.
view_in_ar
03
Coordinated drawings
Views and documents maintained with the information model.
view_in_ar
Technical sequence
From information requirement to documentation.
Defined checks keep data sources, use, and quality clear.
view_in_ar
ARILVO / 02BIM Modelling
01east
Information requirements
We define model uses, content, data, and delivery criteria.
02east
Model development
We build MEP geometry and parameters within scope.
03east
Review and coordination
We check consistency, clarity, and project references.
04check
Deliverable extraction
We produce drawings, schedules, and views from the reviewed model.
Deliverables and outcomes
A model connected to reviewable outputs.
Deliverables follow the agreed model use and project phase.
01
Discipline MEP BIM model
check_circle
02
Coordinated views and drawings
check_circle
03
Model schedules and data
check_circle
04
Agreed information package
check_circle
